29 parameters

Research parameters reported

Sample aspiration

RBC, MCV, HCT, RDW-CV, HGB, MCH,
MCHC, PLT, MPV, , WBC, LYM#, LYM%,
MON#, MON%, NEU#, NEU%, EOS#,
EOS%, BAS#, BAS%

9 parameters:
RDW-SD, PCT, PDW, P-LCC, P-LCR, AL#, AL%, IG#, IG%

Open tube

Throughput

Samples

Sample volume

CBC mode: ≥ 64 samples per hour
CBC+DIFF mode: ≥ 48 samples per hour

Whole blood (venous and capillary)
Pre-dilutes whole blood

CBC mode: ≤ 20 μL
CBC+ DIFF mode: ≤ 25 μL

Cleaner

Reagents

Interface ports

EasyCleaner (50 mL)

Diluent (20 L)
Lyse 1 (200 mL)
Lyse 2 (500 mL)

4 USB ports, 1 LAN
port that supports
bidirectional HL7
protocol

Export of parameter results

Quality control

Linearity ranges

External laser printer or inkjet printer (various printout formats and user-defined formats)
External USB flash disk
Laboratory information system (LIS)

Tri-level controls (L, N, H) QC statistics:
Mean, SD, CV%, Levey-Jennings
and X-bar

PLT: 0–3000 × 109/L
RBC: 0–8.5 × 1012/L
WBC: 0–300 × 109/L
HBC: 0–250 g/L

Dimension

Weight

Display

364 mm (L) x 431 mm
(W) x 498 mm (H)

26.5 kg

10.4 inch TFT touch screen
