3 Part Hematology Analyser
Unique Features
Parameters
| Throughput | ||||
| 60 samples/hour | ||||
| 50 seconds, time to results, OT inlet | ||||
| Sample volume | ||||
| Opentube(OT): 110μL Capillary | ||||
| (MPA): 20 μL | ||||
| Prediluted: 20 μL | ||||
| Cappiercer: 250 μL | ||||
| Autosampler: 300μL | ||||
| Data Storage | ||||
| 50 000 samples with histograms | ||||
| Display | ||||
| 7” TFT touch screen | ||||
| Interface ports | ||||
| 4 USB ports, Supports XML / HL7 protocol | ||||
| 1 LAN port that supports LIS/HIS communication through HL7 protocol | ||||
| External USB Printer Connectivity | ||||
| Data can be transferred to USB Storage as PDF/Excel | ||||
| Precision (Typical) | ||||
|
WBC CV ≤ 1.7% / RBC CV ≤ 0.9% / MCV CV ≤ 0.4% / HGB CV ≤ 0.5% / PLT CV ≤ 3.0%
|
||||
| Model characteristics | ||||
| Basic | Standard | Cap | Sampler | |
| Built-in tube mixer | • | • | ||
| Micro-pipette adapter (MPA) | • | • | • | |
| Maintenance-free shear valve | • | • | • | • |
| Pre-dilution mode | • | • | • | • |
| Cap-piercing device | • | • | ||
| Autosampler | • | |||
